Flashing Profiles

#1(R) Universal Ridge Cap
#1(H) Universal Hip Cap

#2(R) Standard Ridge Cap
#2(H) Standard Hip Cap

#3 Rake & Corner (AG)
#78 Rake & Corner (PBR)

#4 Base Angle (AG)
#5 Base Angle (PBR)

#7 Gable Trim

#8 “J” Trim (AG)

#9 “J” Trim (PBR)

#10 Double Angle

#11 Universal Sidewall

#12 Drip Cap (AG)

#13 Drip Cap (PBR)

#14 Post Trim

#15 Universal Endwall

#16 “F” & “J” (AG)

#17 “F” & “J” (PBR)

#18 Inside Corner

#19 Overhead Door Trim (AG)

#20 Overhead Door Trim (PBR)

#21 Face Mount Cannon-cover

#22 “F” Trim

#24 Residential Rake

#25 Formed Valley

#27 Notched Gambrel

#28 “L” Flashing

#29 Jamb Trim

#30 Offset Cleat

#31 Extended Rake (AG)
#79 Extended Rake (PBR)

#32 Sculptured Rake

#33 Commercial Rake

#34 Headwall Counter Flashing

#37 SS Sidewall

#38 Header Trim

#39 XL Universal Ridge Cap

#40 XL Standard Ridge

#41 Stucco Stop

#42 SS Valley

#44 Small Eave

#45 Eave Trim

#47 Cleat

#48 Z Flashing

#49 Gable Rake Trim

#50 Eave Gutter – Small

#51 LG Eave Gutter

#52 Commercial Gutter

#53 Sculptured Gutter

#54 Commercial Gutter

#55 Commercial Gutter

#56 Gutter

#58 PBR Gutter Hanger

#65 Sculptured Downspout

#67 Transition Flashing

#77 Valley Cover

#80 Peak Cap

#82 Hat Channel

Downspouts
#60 4×5
#61 3×5
#62 4×4
#63 3×4

Elbows
#68 4×5
#69 3×5
#70 4×4
#71 3×4

PBR Ridge Cap

HOUSE FLASHING DETAILS

BUILDING FLASHING DETAILS
